Description
Canadian Eagle 330 Watt Solar Module is available here as a pallet of 30 Canadian-built CS1H-330MS panels from our remaining Mississauga inventory.
Pallet Of 30 Canadian Built CS1H-330MS Mono PERC Solar Modules – 9.90 Kilowatt Array
Limited quantity note: These Canadian Eagle modules were originally built for us by Canadian Solar in Mississauga. Since that facility has closed, this is remaining stock from that production run. We currently have about 200 modules left in inventory.
Canadian Eagle CS1H-330MS is a robust Canadian-built Mono PERC solar module for both on-grid and off-grid applications. This listing is for a full pallet of 30 modules, making it a strong value for larger residential, farm, commercial, or remote power projects.
Key Features
- Canadian-built black frame Mono PERC module
- High-density design for better use of roof and rack space
- Strong low-light performance and improved shading tolerance
- 15-year enhanced product warranty on materials and workmanship
- 25-year linear power output warranty
- Heavy snow load up to 5400 Pa and wind load up to 2400 Pa
Electrical Data – CS1H-330MS (STC)
| Nominal Max. Power (Pmax) | 330 W |
| Opt. Operating Voltage (Vmp) | 37.0 V |
| Opt. Operating Current (Imp) | 8.92 A |
| Open Circuit Voltage (Voc) | 44.2 V |
| Short Circuit Current (Isc) | 9.68 A |
| Module Efficiency | 19.6% |
| Power Tolerance | 0 ~ +10 W |
Electrical Data – CS1H-330MS (NMOT)
| Nominal Max. Power (Pmax) | 244 W |
| Opt. Operating Voltage (Vmp) | 34.2 V |
| Opt. Operating Current (Imp) | 7.14 A |
| Open Circuit Voltage (Voc) | 41.3 V |
| Short Circuit Current (Isc) | 7.81 A |
Mechanical Data
| Dimensions | 1700 x 992 x 35 mm |
| Weight | 19.2 kg (42.3 lbs) |
| Cell Type | Mono-crystalline |
| Front Cover | 3.2 mm tempered glass |
| Frame | Anodized aluminium alloy |
| J-Box | IP68, 3 bypass diodes |
| Cable | 4.0 mm2 (IEC), 12 AWG (UL) |
| Cable Length | 1350 mm including connector |
| Connector | T4 series or H4 UTX or MC4-EVO2 |
| Packaging | 30 pieces per pallet / 780 pieces per 40′ HQ container |
This is the remaining stock from a dedicated Canadian-built production run. Once these are gone, we do not expect to replace them with more of the same Mississauga-built modules.
Canadian Eagle 330 Watt Solar Module pallet inventory is limited to the balance of this Mississauga-built production run, so this listing is aimed at customers who want a full matched pallet while stock is still available.
westrock –
Brand New Pallet Of Canadian Eagle Solar 330 Watt Mono-Perc Solar Modules, Priced Way Below Market Price!
