Description
Best Deal In North America On A Waterproof 36 Volt Lithium Replacement For Trolling Motor Batteries
The 36 Volt 30 Amp Hour CanLiFe lithium trolling motor battery is designed for use
Run Time Estimate:
1 x 36 Volt 30 AH Module = Approximately 6 Hours Of Run Time On A 50 Pound Thrust Trolling Motor On A Medium Setting. Add Additional Battery Modules To Extend Run Time.
Functional Specifications
Voltage: 37.0 Volt
Amp Hours: 30 Amp Hours
Continuous Discharge: 80 Amps
Peak Discharge: 240 Amps (1 Second)
Dimensions: 3300mm/13″L x 171mm/6.74″W x 219mm/8.63″H
Weight: 22 lbs./10kg
Cell Chemistry: LiFeP04
BATTERY FEATURES:
– Compact and only 40% of the weight of comparable lead acid batteries
– Up to 8 times more cycles than lead acid batteries
– Faster charging and lower self-discharge
– Delivers twice the power of lead acid batteries, even high discharge rate, while maintaining high energy capacity
– Super safe chemistry reducing the risk of explosion or combustion due to high impact, over-charging or short
circuit situation
– Rugged impact resistant ABS case and cover flame retardant to UL94:V0
– Battery Management System (BMS) controls the parameters of the battery to provide optimum safety and performance
– BMS enhanced design balances the battery cells and protects against overcharging and discharging
Battery Care:
- Charge using only compatible charging systems
- Store at around 50% charge in cool, dry conditions
- Do not mix with other battery technologies directly
- Always charge at above freezing temperatures, unless configured properly
- Never over charge, over discharge, or over load your cell
- Ensure they are used within the proper operating temperature range
General Care:
maintain safety.
Once installed in a proper system, they are very simple to maintain and utilize.
- Charging should be performed using a CC – CV (Constant Current – Constant Voltage) system.
- NEVER charge at or below temperatures -20 Celsius
- Optimal charge and discharge rates for longevity range from 0.1C to 0.5C.
- Store out of direct sunlight, in a cool, dry place to help avoid cell deterioration.
- Charge at least once every six months, when in storage, to combat self discharge. LiFePO4 cells generally do not like to rest in a fully charged or full discharged state for any period, this will accelerate capacity and performance loss.
- Standard operating range for usable Amp hour (Ah) capacity is 20% – 100%. Depth of Discharge (DoD) 80%.
- Batteries are shipped in a partial state of charge. Charge before using.
- If a pack becomes completely discharged for any period, charge to full immediately.
