Schauer JAC2024 24 Volt 20 Amp
Fully Automatic Multimode Electronic Charger With SB-50 Grey Connector
Intelligent chargers follow battery impedance to end of charge cycle for all battery types. Fully automatic. Red LED indicates AC power on,
yellow LED indicates battery is charging, green LED indicates float mode.
- Charge control: constant current charge to a constant voltage, then to a float standby.
- Current limiting.
- Fully automatic 3 stage charger can be left on the battery in maintaining/float mode.
- Can be set for any type lead acid battery, including conventional, maintenance free, deep cycle, gelled-type, valve regulated batteries.
- Cyclic Voltage: Flooded 2.47 volts/cell; Gel & AGM 2.4 volts/cell. May be preset to customer’s specification for battery type.
- Not intended for use as a DC power supply.
- Continuous – 100% duty cycle.
- Low voltage start: will start charging a deeply discharged battery with low terminal voltage.
- 120/240 VAC Input
